Swage Spacer, Hex, Black Oxide, Brass, 0.139" Shank OD, #3 Screw, 9/16" Body Length
Part ID: BR6336D-0.562-51
Outside Diameter: 0.139"
Inside Diameter: 0.109"
Panel Thickness: 1/8"
|Swage Anvil Code||220-3|
|Swage Punch Code||139|
|Finish Desc. (Spec)||
The unthreaded turned down section allows for the part to be secured to the circuit board via a swaging process. The swaging of the part curls the part back onto the board. This curled section keeps the part firmly in place. Parts are thoroughly tested to ensure that proper swaging will not cause excessive cracking or flaking. The hex shape allows for greater torquing as the flat sides allow for wrench tightening. Brass is corrosion resistant, nonmagnetic, and easily machinable. Base metal is yellow, but many plating options are available when different colors are required.
Stock and Lead Time
|Stock to Plate||0||2 to 3 weeks|
|Manufacture Lead Time||12-13||Weeks|
