Male-Female Standoff, Hex, Unplated, Nylon, M3.5x0.6, 11mm Body Length
Part ID: NY5173-11.0-00
Technical Specifications
Material Grade (Alloy): |
Nylon 6/6 (LP-4102, MIL-P-46060) |
---|---|
Profile | Hex |
Outside Diameter | 6.0mm |
Body Length | 11mm |
Male Thread |
Thread Size: M3.5x0.6 Thread Length: 4.76 |
---|---|
Female Thread | M3.5x0.6 |
Finish Desc. (Spec) |
Unplated (Plain) |
Compliant To | RoHS, WEEE, REACH, DFARS, Conflict Minerals |
Product Description
Male-female standoffs are used to separate, position or connect components in an assembly. They remain widely used in computers and electronic equipment to separate circuit boards for airflow and allow clearance for installed components. However, as these come in a wide array of sizes and threads, nearly every industry has used them as thread adapters, spacers, and connectors among other unique applications. The hex shape allows for greater torquing as the flat sides allow for wrench tightening. Nylon material offers an excellent combination of mechanical performance and cost.
Stock and Lead Time
Stock | 0 | Available |
Manufacture Lead Time | 11 | Weeks |
Pricing as Unplated
Quantity | Online Price |
---|---|
100 | 0.000 |
250 | 0.000 |
500 | 0.000 |
1,000 | 0.000 |
2,500 | 0.000 |
5,000 | 0.000 |
10,000 | 0.000 |
25,000 | 0.000 |
50,000 | 0.000 |
If you wish to see distributor prices, login or create an account and request to be approved as a distributor.
To order, please send a purchase order to info@lyntron.com or contact your local distributor. Orders may be adjusted to meet line and/or order minimums. See general terms for details.
